Pressure transducers are housed in tubes on the inlet rake of NASA's F/A-18 High Alpha Research Vehicle (HARV) to test pressure distortion patterns at different angles of attack.
EC94-42514-11
Pressure transducers are housed in tubes on the inlet rake of NASA’s F/A-18 High Alpha Research Vehicle (HARV) to test pressure distortion patterns at different angles of attack. Located at the engine face, these probes provide information on how to adjust the engine to accommodate the distortions.April 8, 1994NASA Photo / › F-18 HARV Project Description
