The nose of NASA's single-seat F-16XL #1, featuring a delta "cranked arrow" wing, offers a different perspective when viewed from above in a partially-lit hangar at the Dryden Flight Research Center, Edwards, CA.
ED95-43029-5
The nose of NASA’s single-seat F-16XL #1, featuring a delta “cranked arrow” wing, offers a different perspective when viewed from above in a partially-lit hangar at the Dryden Flight Research Center, Edwards, CA. The aircraft was most recently used in the Cranked-Arrow Wing Aerodynamics Project (CAWAP) to test boundary layer pressures and distribution.March 8, 1995
NASA Photo
