MTB: Comparing Full Rotor and Rotor Disk – Six Rotors Tunnel Speed 20fps 0-Pitch: m2cn
This figure compares both rotor disk and full rotor configurations for a six-rotor Multirotor Test Bed experiment at a wind tunnel speed of 40 ft/sec. Iso-vortices are colored with pressure coefficient, with red indicating high and blue indicating low.
Image Credit: NASA/Ames, Jasim Ahmad
